Cut-to-Length Lines

Cut-to-Length Lines

A Cut-to-Length Line or CTL takes flat-rolled steel, or steel coils, unrolls it, levels it and cuts it to desired length as a sheet. Cut-to-Length lines are also known as blanking lines, level lines or shear lines.

Fifty years ago most steel sheet was purchased directly from the mills. However, it became more efficient to send the master coils to a service center where the material could be processed for the end user.

Cut-to-length lines or CTL lines can be start and stop, such as in heavy gauge metal processing which process materials up to 1" thick. Alternatively, cut-to-length lines can operate as a free loop on lighter gauge materials up to 0.06" thick. The basic parameters of cut-to-length lines (CTL Lines) are steel coil width, coil weight, material type, minimum and maximum thickness, tolerance, finished sheet length range and desired flatness.

Galaxie is one of the world’s largest dealers in used cut-to-length lines. Our cut-to-length line offerings include well-known brands such as: Herr Voss, ProEco, Delta Brands, Red Bud, Rowe, and Braner.
60" x .135" x 40,000lbs 6-HI Herr Voss Cut To Length Line

HERR VOSS

60" x .135" x 40,000lbs 6-HI Herr Voss Cut To Length Line

1500mm x 6mm x 50,000# Rotary Shear Cut-to-Length Line Year 2018

TEKMAK

1500mm x 6mm x 50,000# Rotary Shear Cut-to-Length Line Year 2018

1500mm x 2mm x 20 Ton  Vigano Loop Cut to Length Line

VIGANO

1500mm x 2mm x 20 Ton Vigano Loop Cut to Length Line

1600mm x 3mm x 15 Ton Guida 6-HI Cut To Length Line with Flying Shear

GUIDA

1600mm x 3mm x 15 Ton Guida 6-HI Cut To Length Line with Flying Shear

54 x .104" x 10,000# Dahlstrom Cut to Length Line

DAHLSTROM

54 x .104" x 10,000# Dahlstrom Cut to Length Line

47" x .0393" x 33,000# FIMI Cut to Length Line with 2 Packing Stations

FIMI

47" x .0393" x 33,000# FIMI Cut to Length Line with 2 Packing Stations

32" (800mm) x .315" (8mm) x 10,000# Cut-to-Length Line

Not Specified

32" (800mm) x .315" (8mm) x 10,000# Cut-to-Length Line

31" (800mm) x 2.5mm x 22,000# Rotary Cut-to-Length Line (2017)

Not Specified

31" (800mm) x 2.5mm x 22,000# Rotary Cut-to-Length Line (2017)

30" x .090" x 20,000# Rowe Cut-to-Length Line

ROWE

30" x .090" x 20,000# Rowe Cut-to-Length Line
