60" (1530mm) x .060" (1.5mm) x 40,000lbs Cincinnati Herr Voss Loop Cut to Length Line

Brand
CINCINNATI MACHINES

Model
Not Specified

Type
Cut To Length Lines

Stock #
605597

Condition
Used

Year

Request a Quote
Have one to sell?
Coil Weight 40000 pounds
Width 60 inches
Thickness .119 inches
ID 20 inches
Max OD 72 inches

Equipped With

Line Direction: Right to Left

Complete Line with the Following Components:

L-Type Coil Car

Mandrel Uncoiler
Min Coil OD:  27" (700mm) - Max Coil OD: 72" (1850mm)

Edge Control System

Peeler Table

Entry Edge Guides

Pinch Rolls

First Leveler:  Herr Voss 4-HI
Roll diameter: 40 mm (1.57 inch)
19 work rolls

Ink Jet Printer
Edge Trimmer
Scrap Choppers
Entry and Exit Cascade Rolls
Pit Cross Over Table
Servo Feed Roll
Shear

Stacker System

Complete Line with Controls, Hydraulics, Electrics

Installed and in Operation
