48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler
48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler
48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler
48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler
48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler
  • 48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler
  • 48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler
  • 48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler
  • 48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler
  • 48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler

48" (1250mm) x .031" (.80mm) x 35,000# Fimi Tin Plate CTL Line with Rotary Shear and Cassette Leveler

Brand
FIMI

Model
Not Specified

Type
Cut To Length Lines

Stock #
605209

Condition
Used

Year

Request a Quote
Have one to sell?
Coil Weight 35000 pounds
Width 48 inches
Thickness .031 inches

Equipped With

Revamped in 2008 and 2019
All power and electrical connections of the machine, all of the devices, PLC, and software are new

General Specifications:
Process Materials: Tinplate and Stainless Steel (Raw and Annealed)
Coil Width Range: 14"-48" (350mm-1250mm)
Thickness Range: .005"-.031" (.12mm-.80mm)
Max Speed: 330 ft/min (100m/min)
Coil ID: 16" and 20" (400mm and 508mm)
Finished Sheet Length Range: 20"-78" (500mm-2000mm)
Max Coil Weight: 16 Tons

Complete with the Following Components:
Coil Storage Ramp for Two Coils
Coil Car
Uncoiler
Pinch Rolls
Leveler with Two Cassettes
Pinch Rolls
Pin Hole Detector
Pit with Cascade Conveyors
Feed Rolls
Electronic Thickness Gauge
Rotary Shear
Scrap Bin
Stacker with Three Stations
Exit Bundle Conveyor
