94" (2400mm) x 1" (25mm) Spiral Pipe Mill NEW

Brand
Not Specified

Model
Not Specified

Stock #
604598

Condition
Not specified

Year

Tube Diameter 94 inches
Max. Wall Thickness 1 inches

Equipped With

Incoming Coil Specifications:
OD Range: 1200mm-1600mm
ID Range: 508mm-760mm
Strip Width: 450mm-1550mm
Strip Thickness: 6mm-25mm
Max Weight: 30T

Pipe Specifications:
OD Range: 300mm-2400mm
Pipe Wall Thickness: 6mm-25mm
Spiral Angle: 40-80 degrees
Pipe Length: 8m-18m
Welding Speed: .8m/min-2.5m/min
Delivery Speed: .6m-3m/min
Production Capacity: 220T per 8 Hours

Complete Line with the Following Components:
Uncoiler
Pinch Rolls and Leveler
Shear and End Welder
Three Electric Guide Rollers
Edge Millers
Surface Cleaning
Feeder
Guide Beams
Front Bridge
Forming Machine
Inside Welding Device
Outside Welding Device
Back Bridge
Support
Flying Cutting Car

Other Supporting Equipment:
Hydraulic System
Control System
Flux Platform
Walking Platform
Two Welding Wire Disc
Four Lincoln Welders
Butt Welding Car
Flux Selection and Drying System
Slag Removal Machine
Air Compressor
Connection Cables
Two Plasma Cutting Machines

Process Flow
Uncoiler – Pinch and leveler – Guide rollers – Cutting and end welder – Guide rollers – Pinch roll – Loop – Edge slitter1– Edge slitter2 – Guide rollers – Surface cleaning – Delivery machine – Guide beam – Forming machine – ID welding – OD welding – Plasma cut-off – pipe discharge.
