Brand: Metlsaw
Model: CS-4
Maximum material width: 48"
Maximum material thickness: 8"
Programmable backgauge range: 96"
Backgauge speed: 0 - 200 IPM
Maximum sawblade diameter: 28"
Cutting speeds: Up to 500 sq. in./min. (aluminum)
Carriage feed rate: 0 - 600 IPM
Blade motor: 30 H.P.
Voltage: 480 volt 3 phase (80 amps)
Backgauge: DC servo motor
Carriage drive: DC servo motor
Air requirements: 30 CFM
Features:
Cuts solids, extrusions, tubes or rounds
Automatic fast forward blade travel
Universal clamping for single or bundle cutting
Variable cutting speed according to type & thickness of material
Servo controlled carriage drive provides smooth, finely controlled cutting speeds
Variable cutting lengths allow very small pieces to be cut as efficiently as large pieces
CRT display shows actual position of backgauge at all times
Automatic proportional speed control (automatically adjusts carriage traverse speed to
thickness of material)
Equipped with:
Allen Bradley Panelview 1000 programmable controller
Programmable precision backgauge automatically feeds to 96" (maximum)
Two sets of safety light curtains
Chip collector system
Extra saw blades
