Thickness Range: .125” - .625”
Entry Coil ID: 24” - 30”
Exit Coil ID: 30”
Entry & Exit Coil OD: 80”
Equipped with the following components:
- 90,000# 3 Position Entry Storage Saddles
- 90,000# Pit Type Coil Loading Car
- 90,000# Dual Cone
- Free Standing Floor Mounted Hold Down With Hardened Steel Roll
- Telescoping Peeler Blade
- Hardened Steel Entry Pinch Rolls
- Hydraulic Cylinder Positioned Adjustable Side Guides
- Automatic Edge Guide
- 5 Roll Flattener With Quick Opening Rolls
- Entry Crop Shear Tail Feed Rolls
- Hydraulic Guillotine Downcut Entry Crop Shear
- Scrap Gate
- Powered Scrap Car
- Hydraulic Cylinder Positioned Side Guides
- 3 Head 14" Arbor x 19" OD Knife Turret Slitter 400HP DC
- Pivoting Slitter Table
- Slitter / Recoiler Threading Table
- Free Standing Overarm Separator With 1 Spindle
- 1 Spare Overarm Separator Spindle
- 90,000# 30” Recoiler 400HP DC
- Recoiler Tail Hold Downs
- 90,000# Floor Level Coil Unloading Car
- Coil Unloading Car Electronic Scale
- 90,000# 4 Arm Exit Storage Turnstile
- Water Recirculating System
- Hydraulic System
- Electrical System
