72" x .500" x 80,000# Pro Eco Slitting Line with Two Slitting Heads

Brand
PRO ECO

Model
Not Specified

Stock #
605284

Condition
Used

Year

Width 72 inches
Thickness .500 inches
Coil Weight 80000 pounds
Arbor Size 10.5 inches

Equipped With

General Specifications:
Maximum Width: 72”
Maximum Thickness: .500”
Minimum Thickness: .017”
Maximum Coil Weight at Uncoiler and Recoiler: 80,000#
Entry Coil ID at Uncoiler: 20” to 32”
Exit Coil ID at Recoiler: 24” with 11/16” Hydraulic Gripper Slot
Entry Coil OD: 36” - 72”
Exit Coil OD: 36” - 72”
Line Speed (Full Torque): 150 FPM
Maximum Line Speed: 500 FPM
Maximum Slitting Capacity (100,000 PSI Tensile): 5 Cuts of .500”, 11 Cuts of .135”, 21 Cuts of .060”

With the Following Components:
Entry Floor Type Coil Car
Double End Cone Uncoiler
Peeler System
Flattener Rolls
Entry Crop Shear
Edge Guides
Two Slitter Heads
Two Scrap Winders
Recoiler Feed System
Recoiler
Exit Coil Car

Tooling, Knives
