72" x .250" x 60,000lbs Herr Voss -Butech Cassette CTL Line

Brand
HERR VOSS

Model
Not Specified

Stock #
102038G

Condition
Used

Year

Coil Weight 60000 pounds
Width 72 inches
Thickness .200 inches

Equipped With

Materials: Hot / Cold Rolled Steel, Pickled and Oiled, H.S.L.A Yield Strength: 85,000 PSI max on Leveler, 65,000psi max yield Strength on Shear Thickness Range: .060” to .200” Coil ID: 20” to 30” Coil OD: 80” Max Max Width: 75” Line Speed: 150 fpm Min Sheet Length: 12” Max Sheet Length: 30’ Line Direction: Left to Right Complete Line with the Following Components: 3 Coil Storage Ramp Pit Type Coil Car Double Cone Mandrel Uncoiler Wichita Water Cooled Brakes AC Feed Up Drive Free Standing Hold Down Roll Assembly Peeler Table Roller Inspection Table Motorized Edge Guides 72" x .200" Butech Cassette Leveler General Specifications: Manufacturer: Butech Year of Manufacture: 2002 Material: HR, HRHS, HRPO Yield Strength: 85,000 PSI max. Strip Thickness: .200 " maximum, .060" minimum Strip Width: 72" max., 24" min. Line Speed: 0 to 326 or 400 FPM max. as determined with customer Line Direction: Left to Right Guide Reference: Centerline (2) 250 HP DC Motors (17) Roll Leveler Specifications: Work Roll Quantity: 17, 8 up, 9 down Work Roll Size: 2.750" (70 mm) dia. x 80" (2030 mm) face Back Up Flights: 7 top and bottom Strip Thickness Range: 0.200" max., .060" min. Many spare parts including work rolls and back up rolls Feed Roll Unit Herr Voss Shear Max Thickness: .250” Down Cut Design 65,000psi Shear Strength Number of Cuts: 70 per minute Bowtie Blade Spare Shear Blades Drop Type Stacker Max Sheet Length: 30’ Powered Rolls Pack Runout Roller Conveyor Push Buton Operator Station Allen Bradley PanelView Plus 1500 Allen Bradley PLC Complete with Electrics, Hydraulics, Controls and Drawings
