Thickness Range: 24ga to 10Ga
Coil Weight Capacity: 40,000#
Sheet Length: 24” - 20’
Coil OD: 72”
Coil ID: 20” - 24”
Complete Line With:
L-Type Coil Car
Floor Standing / Self Contained Hydraulics
Powered Conveyor Rolls of V-Deck
Mandrel Uncoiler
Sliding Base
4 Leaf Hydraulic Expansion
Powered Hold Down Roll
Disc Brake
Air Clutch & Feed Up Drive
Peeler Table
Edge Guides
Pinch Rolls
Herr Voss 4HI Precision Leveler. (Rebuilt)
Model: LH-84-1.75-19-7
Thickness Range: .028” - .125”
1 3/4” Dia. Work Rolls
84” Roll Face
7 Flights Top & Bottom Back-Ups
5 Flights Motorized with Individual Adjustments
75 HP DC Drive
Herr Voss 4HI Precision Leveler
Model: LH-82-2.187-19-7-4HI
Thickness Range: .036” - .164”
7 Flights Top & Bottom Back-Ups
5 Flights Motorized with Individual Adjustments
Digital Read Out Roll Positioning
125 HP DC Drive
Hump Table
Cincinnati Shear
Twin Belt Gauging Table
Positive Stop
Motorized Length Adjustment
In Line Printer
Cincinnati Stacker (Updated By Delta Brands)
Hydraulic Lift Table
Blower
Side Squaring
End Stop
Motorized Width Adjustment
End Discharge Run Out Conveyor
Two Sets of Leveler Controls
Digital Length Measuring
Bardac Digital Drives (Drive Web Ready)
Model PXL115
50/60 HZ
Spare Rolls and Spare Parts
Complete Line Can Be Inspected Under Power and Operating
