Strip Width: 20"-72" (508mm-1800mm)
Strip Thickness: .075"-.500" (1.9mm-12.7mm)
Coil ID: 20"-30" on entry, 24" on Exit (508mm-762mm on entry) (610mm on Exit)
Coil OD: 36"-80" (914mm-2032mm)
Max Coil Weight: 60,000#
Line Speed: 150 FPM (50 MPM)
4 Cuts of .375" at 80,000PSI
4 Cuts of .500" at 50,000PSI
Electrical Upgrades: Allen Bradley 1397 Digital Drives (2006)
Line Direction: Left to Right
Complete Line with the Following Components:
Entry Pit Type Coil Car
Coil Saddle
Double Cone Uncoiler
Peeler and Hold Down Roll
Entry Edge Guides
Automatic Edge Controller
Pinch Rolls
Three Roll Flattener
Entry Crop Shear
Edge Guides Pinch Rolls
Two Slitting Heads
Two Scrap Choppers
Goose Neck Conveyor
Carry Over Table
Recoiler with Overarm Separator
Exit L-Type Coil Car
Knives, Rubbers, and Tooling,
Electrical Upgrades to Allen Bradley 1397 Digital Drives (2006)
