60" (1600mm) x .125" (3.2mm) x 40,000lbs Loop Dual Injector Head Slitting Line (2016)

Brand
Not Specified

Model
Not Specified

Type
Slitters & Slitting Lines

Stock #
605602

Condition
Used

Year
2016

Request a Quote
Have one to sell?
Width 1600 millimeters
Thickness 3.2 millimeters
Coil Weight 40000 pounds

Equipped With

Complete Line with the Following Components:

Raw Material Coil Seat &

Entry Coil Car

Single-Mandrel Uncoiler
Hydraulic Expansion
Slidding Base
Powered Hold Down Roll
Outboard Bearing Support

 Peeler Table


Top & Bottom Film Laminating Equipment
Paper Winder

Leveling/Flattening Unit (or Sheet Feeder)

Entry Shear

Pit Cross Over Table

Cascade Rolls
LOOP Depth: 6000mm~10000mm

Entry Guides and Pinch Rolls

Slitting Head

Scrap Winder / Chopper

Carry-over Bridge & Loop Pit

 Tension Stand / Control Station

 Exit Shear & Deflector Roll

 Recoiler & Pusher Plate

 Exit Coil Support & Paper Interleaving Machine

 Exit Coil Car

Complete Line with Hydraulics, Controls, Electrics

Installed and in Operation
