Materials: CRS, Alum, Galv, Pre-Paint
Min./Max. Coil Width: 6" - 60"
Thickness Range: .020" - .104"
Maximum Coil Weight: 20,000lbs
Coil I.D.: 20" - 24"
Maximum Coil O.D.: 64"
Minimum Slit Width: 3"
Line Direction: Left to Right
Stacker Length: 1 - 12'
Maximum Bundle: 18" x 10,000lbs
Line Speed: 20 - 200 FPM / 20-150 FPM
Complete with the Following Components:
Entry Coil Car:
Low Boy Type
Floor Mounted
Powered Lift and Traverse
Mandrel Uncoiler:
Mandrel Type
Powered Expansion
Feedup Drive
Holddown with Powered Snubber
Loop Control with Dancer Arm
Self Contained Hydraulic Unit
Entry Unit:
Extending Blade Peeler
Powered Entry Pinch Roll
Manual Side Guides
Manual Side Guides
Slear Unit:
Powered Entry Pinch Rolls
Slitter Head with Hub Type Tooling (5" Diameter Arbor)
Fifteen (15) Slitter Knives
Powered Pinch Rolls
Flattener with Six (6) Work Rolls in a 3/3 Configuration
Powered Exit Pinch Rolls
Down Cut Shear on Traversing Track (Single Rake Blade)
One (1) Spare Set of Shear Blades
Two (2) Scrap Winders:
Minimum/Maximum Scrap Width: 0.250" - 1"
Level Wind
Automatic Scrap Dump
Stacker :
Manual Adjustable End Stop
Manual Adjustable Side Tampers
Avon Scissor Lift Table with Powered Roller Conveyor Top
Three (3) Sheet Tampers
Five (5) Blank Dividers
Lift Table with Powered Conveyor Top
Powered Side Discharge Conveyor :
12' Length
20,000# Capacity
Twin Powered Rubber Belts
Electronics:
Main Operators Console with Allen Bradley Touch Screen and PLC
Aux. Control Consoles
AC/DC Cabinet
