-30,000# Max. Coil Capacity
-72" Max. Coil O.D.
-48" Max. Coil Width
-63" L x 72" W Flat Table with Powered Roller Conveyor
4.5" Dia. Conveyor Rolls
-36" Wide x 33.5" Long "V" Cradle
-Distance from floor to bottom of "V" Cradle: 24.5" in tipped position
-Motor driven Screwjack for raising/lowering "V" cradle: Approx. 24" Vertical Lift
-Dual driven chains for tipping
-Driven wheels
-Passline: 41.5" from floor to top of Roller Conveyor
-Overall Size: 125" L x 97" W x 89" High
