19 Meter x 62 Tons/Hour Rotary Hearth Furnace NEW

Brand
Not Specified

Model
Not Specified

Stock #
604940

Condition
New

Year
2023

Chamber-W 19 meters
Chamber-L 4000 millimeters
Chamber-H 4000 millimeters
Max Temperature 1300 celsius
CNC Control yes

Equipped With

This heating furnace is used for the heating process of steel billet products. Party B shall design a fully automated rotary bottom annular heating land production line according to the requirements, mainly composed of the feeding platform of the annular furnace, feeding conveyor roller, feeding and loading manipulator, furnace bottom mechanical equipment, tapping manipulator, furnace door mechanism equipment, annular heating furnace system, and the entire line automation control system. During the production process, the operator only needs to set process parameters, and the transfer and heating process of products in the heating production line are automatically controlled by the equipment itself.

After receiving the steel charging signal, the charging furnace door automatically opens, and the steel charging manipulator automatically feeds the steel billets on the charging roller table outside the furnace into the furnace. Then, the steel charging manipulator returns to the loading starting position and waits. The charging furnace door automatically closes, and the furnace bottom rotates and operates according to the cycle set by the system. The billet passes through the preheating section, the heating section, the soaking section, and the tapping and reheating zone in the furnace in turn. After the billet is heated, it reaches the discharge furnace door position. Upon receiving the tapping signal, the discharge furnace door automatically opens, and the tapping manipulator enters the furnace to take out the billet and deliver it to the designated position.

The heating fuel of the heating furnace is natural gas, which is combusted using a natural gas low nitrogen burner. The furnace adopts forced exhaust gas from the fan, and the flue gas is discharged into the atmosphere through the flue, fan, and chimney. The buyer sends natural gas to the furnace side, and the gas is sent to each heating section of the furnace after pressure regulation. For the needs of operation and maintenance, corresponding platforms and ladders have been set up near the inner and outer rings of the furnace, the furnace top, and the main regulating valves to facilitate personnel access.

Material brand: J55, K55, N80, P110

10 20 45 16Mn 12Cr1MoV 15CrMo

12Cr1MoVG, 27SiMn, GCr15, 37Mn5, 36Mn2V, etc

 Product Incoming Material Specification Table



No.

Diameter (mm)

Length (mm)

Maximum weight per unit (Kg)

remarks

1

 82.55-191

1052~4000

eight hundred and ninety-nine

Round billet



Furnace feeding method

1 Place the blank horizontally;

2 Single row distribution in the furnace;

Heating beat: the fastest speed is 120 tubes/h.

Heating process: provided by the user

Capacity: 62 tons/h.

Technical Performance Table

No.

Item name

unit

data

1

Furnace type



Annular heating furnace

2

purpose



Heating of steel billet before rolling

3

Heating steel grade



See product outline

4

Heating billet length

mm

1052~4000

5

Heating billet specification

mm

Round billet Φ 82.55191

6

Billet charging temperature

Cold charging at room temperature

7

Design maximum temperature in furnace

1300

8

Furnace output (maximum)

t/h

62

9

Fastest tapping rhythm

pcs/h

120

10

Cloth method



Single row fabric, double row fabric

11

Basic dimensions of furnace





11.1

Median diameter

mm



11.2

Furnace bottom width

mm

4200

11.3

Furnace inner width

mm

4500

11.4

Furnace height

mm

1200

12

Angle between loading machine and tapping machine

°

20

13

Cloth corner

°

2 to 5 arbitrary adjustable

14

Fuel (natural gas)





15

Main gas pipe pressure

MPa

0.08-0.1

16

Maximum gas consumption

Nm3/h

3100

17

Maximum air consumption

Nm3/h

33800

18



Nm3/h

40080

19

Section temperature deviation of tube blank in soaking section

±10

20

Air preheating temperature

400

21

Transmission mode of furnace bottom

Hydraulic drive (2 sets arranged at 180 °).

22

control mode

Siemens S7-1500 system

23

Total installed capacity



24



t/h

120

25

Amount of turbid

circulating water

t/h

15


Process description and equipment composition of annular heating furnace

Basic specifications and dimensions of annular furnace

¨        Furnace type: annular furnace

¨        Pitch diameter of annular furnace: D0=19000mm.

¨        Width of annular furnace bottom: B0=4200mm

¨        Inner width of annular furnace: B=4500mm

¨        Furnace clearance height: 950mm for preheating section, 1200mm for other parts

Process description of circular heating furnace

The steel billets are loaded on the loading platform, and then transported to the feeding roller table from the loading platform. The feeding roller table is transported to the lower part of the feeding steel loading machine. Then, the steel billets are loaded into the annular heating furnace by the feeding steel loading manipulator. The steel billets are heated in the furnace and heated to the required temperature. After that, the steel billets are taken out by the tapping manipulator and placed on the designated roller table position under the tapping manipulator.

Workflow: billet loading → billet conveying on the roller table → feeding and loading with a manipulator → heating in the annular furnace → discharging with a manipulator → receiving the roller table.

Equipment composition of annular furnace

1)        Civil engineering foundation: The seller provides the foundation design condition drawing, and the buyer is responsible for the detailed design and construction of the foundation drawing;

2)        Annular furnace system: furnace steel structure (including walkways and railings), furnace masonry, combustion system, air supply system, smoke exhaust system, vent system, furnace water system, etc;

3)        Furnace mechanical equipment: furnace bottom machinery, loading platform, loading roller table, feeding and loading manipulator, tapping manipulator, furnace door opening and closing mechanism;

4)        Hydraulic system, dry oil lubrication system;

5)     Automatic control system in the project: the seller is responsible for the electrical automation and information process automation systems of the annular heating furnace;

6)        Technical data and services within the design scope (including providing personnel training, etc.).



Energy medium contact requirements

 Industrial water

Clean circulating water

Used for installing steel robots, hydraulic stations, smoke exhaust fans, water-cooled partitions, and industrial television cooling.

Water supply pressure: 0.3MPa~0.4MPa

Water supply flow: 120t/h

Water supply temperature: ≤ 35 ℃

Return water flow rate: 120t/h

Return water temperature: ≤ 60 ℃

Safe water

Used for cooling water partitions.

Water supply pressure: 0.2MPa~0.4 MPa

Water supply flow: 60t/h (it is required to restore clean circulating water supply within 30min)

Water supply temperature: ≤ 35 ℃

Turbid circulating water

Used for cooling the water seal of the water seal tank.

Water supply pressure: 0.3MPa~0.4 MPa

Water supply flow: 15t/h

Water supply temperature: ≤ 35 ℃

Compressed air

Compressed air for instruments and actuators

Clean compressed air after oil removal, dust removal, and dehumidification is used by pneumatic shut-off valves, industrial television cameras, and other equipment.

Gas supply quality: dust particle size ≤ 3um dust content ≤ 0.1mg/Nm3

Oil content ≤ 1mg/Nm3 Dew point ≤ - 20 º C (0.5MPa)

Contact pressure: 0.4~0.6MPa

Dosage: 2m3/min

Compressed Air Safety Air Source

When there is a failure in the normal gas supply, it is required to provide a certain safety gas source to meet the emergency operation of the heating furnace valves and instrument actuators, and ensure the safe operation of the heating furnace.

In the heating furnace area, a safety air storage tank for instrument compressed air is provided by the public auxiliary to provide a safety air source for the heating furnace, and a filter is installed in front of the gas storage tank.

Nitrogen

It is used for purging the gas pipeline during the first startup, shutdown, maintenance, and emergency of the heating furnace. It is used intermittently for about 30 minutes each time.

Contact pressure:            0.1 MPa~0.2 MPa

Temperature:                   normal temperature

Purity:                             99.5%

Consumption:                  200 m3/time

Purging time each time: 30 min

Fuel

Low calorific value of natural gas:~9750 kcal/Nm3;

Contact pressure: 0.08~0.1MPa;

Contact flow: 3500 Nm3/h.

Energy medium contact requirements

 Industrial water

Clean circulating water

Used for installing steel robots, hydraulic stations, smoke exhaust fans, water-cooled partitions, and industrial television cooling.

Water supply pressure: 0.3MPa~0.4MPa

Water supply flow: 120t/h

Water supply temperature: ≤ 35 ℃

Return water flow rate: 120t/h

Return water temperature: ≤ 60 ℃

Safe water

Used for cooling water partitions.

Water supply pressure: 0.2MPa~0.4 MPa

Water supply flow: 60t/h (it is required to restore clean circulating water supply within 30min)

Water supply temperature: ≤ 35 ℃

Turbid circulating water

Used for cooling the water seal of the water seal tank.

Water supply pressure: 0.3MPa~0.4 MPa

Water supply flow: 15t/h

Water supply temperature: ≤ 35 ℃

Compressed air

Compressed air for instruments and actuators

Clean compressed air after oil removal, dust removal, and dehumidification is used by pneumatic shut-off valves, industrial television cameras, and other equipment.

Gas supply quality: dust particle size ≤ 3um dust content ≤ 0.1mg/Nm3

Oil content ≤ 1mg/Nm3 Dew point ≤ - 20 º C (0.5MPa)

Contact pressure: 0.4~0.6MPa

Dosage: 2m3/min

Compressed Air Safety Air Source

When there is a failure in the normal gas supply, it is required to provide a certain safety gas source to meet the emergency operation of the heating furnace valves and instrument actuators, and ensure the safe operation of the heating furnace.

In the heating furnace area, a safety air storage tank for instrument compressed air is provided by the public auxiliary to provide a safety air source for the heating furnace, and a filter is installed in front of the gas storage tank.

Nitrogen

It is used for purging the gas pipeline during the first startup, shutdown, maintenance, and emergency of the heating furnace. It is used intermittently for about 30 minutes each time.

Contact pressure:            0.1 MPa~0.2 MPa

Temperature:                   normal temperature

Purity:                             99.5%

Consumption:                  200 m3/time

Purging time each time: 30 min

Fuel

Low calorific value of natural gas:~9750 kcal/Nm3;

Contact pressure: 0.08~0.1MPa;

Contact flow: 3500 Nm3/h.



Preliminary calculation of heating capacity:



Diameter of annular furnace (m)

Feeding and discharging angle

Billet diameter (mm)

Billet length (m)

Unit weight (ton)

Number of furnace loaded pieces

Number of steel taps per hour

Hourly production

Cloth method

19

20

191

4000

0.899

165

69

62.03

Single row fabric

19

20

191

3200

0.719

165

69

49.6

Single row fabric

19

20

191

2400

0.540

165

69

37.2 6



19

20

191

1700

0.382

304

120

45.84

Double row fabric

19

20

191

1052

0.236

304

120

28.3

Double row fabric

19

20

180

4000

0.798

171

76

60.6

Single row fabric

19

20

180

3200

0.638

171

76

48.48

Single row fabric

19

20

180

2400

0.479

171

76

36.4

Single row fabric

19

20

180

1700

0.339

240

120

40.68

Double row fabric

19

20

180

1052

0.210

240

120

25.2

Double row fabric

19

20

160

4000

0.632

171

86

54.3

Single row fabric

19

20

160

3200

0.5056

171

86

43.48

Single row fabric

19

20

160

2400

0.379

171

86

32.59

Single row fabric

19

20

160

1700

0.2686

240

120

32.2

Double row fabric

19

20

160

1052

0.166

240

120

19.9

Double row fabric

19

20

120

4000

0.355

171

120

42.6

Single row fabric

19

20

120

3200

0.284

171

120

34.08

Single row fabric

19

20

120

2400

0.212

171

120

25.44

Single row fabric

19

20

120

1700

0.150

180

120

18.00

Double row fabric

19

20

120

1052

0.0933

180

120

11.19

Double row fabric
