Brand
Not Specified
Model
Not Specified
Stock #
605180
Condition
Used
Year
| CNC Control | yes |
- Material to be painted : aluminium or steel profiles and sheets
- Medium charge dimension : mm 6500 x 300 x 1500 (H).
- Maximum charge dimension : 8000 x 500 x 1500 mm. In this case the bars holding pieces should be loaded at a double step
- Maximum sheets dimension : mm 5.000 x 1500 x 3.
- Maximum charge weight : kg. 120.
- Theoretical production capacity (maximum) :> 18- bars holding pieces/hour equal to. 864 aluminium profiles (considering profiles having a medium weight of 4 kg.) and the plant equipped with n. 1 application unit
> 30 bars holding pieces/hour equal to. 1440- aluminium profiles (considering profiles having a medium weight of 4 kg.) and the plant equipped with n. 2 application units
- Curing temperature : 180-210° C.
- Curing time : 25 minutes about
- Max. oven air temperature : 230°C.
- Electric power installed : 350 kW approx.
- Power : 400Vac,50Hz,3Ph+hearth
- Thermal capacity installed : 500.000+160.000 Kcal/h
