| Capacity | 4.5 inches |
| CNC Control | yes |
Year 1999
Bending Capacity: 4.5" OD X .35" Wall
Maximum Bend Radius: 23.6"
Minimum Centerline Radius: 2"
Maximum Tube Length Over Mandrel: 157.5"
Max Degree Of Bend (C-Axis): 0 - 193 deg.
Plane Of Bend (B-Axis): 0 - 360 deg.
Follower Slide Stroke: 29.7"
Clamp Slide Stroke (Direct Acting): 9"
Horizontal Shift (X-Axis) 23.6"
Axis Speed (Y-Axis Feed): 1575 IPM
Axis Speed (B-Axis Rotation): .78"
Axis Speed (C-Axis Bending): 3.5 RPM
Axis Speed (X-Axis Radius): 394 IPM
Tube Working Height: 47.25
Hydraulic Tank Capacity: 150 gallons
Operating Pressure: 2,000 PSI
Machine is equipped with Addison Data Bend CNC Control & programable plane of bend (B -axis).
