YEAR – 2004
LINE DIRECTION – RIGHT TO LEFT
UNCOILING DIRECTION – OVERWIND
RECOILING DIRECTION – OVERWIND OR UNDERWIND
MATERIALS – COLD ROLLED AND HOT ROLLED STEEL (PICKLED OR BLACK)
THICKNESS – .010” (0.25 mm) MIN., .250” (6.35 mm) MAX.
COIL WIDTH – 72” (1,829 mm) MAX.
COIL WEIGHT – 70,000# (31,751 Kg) MAX. (ENTRY & EXIT)
COIL OUTSIDE DIAMETER – 72” (1,829 mm) MAX. (ENTRY & EXIT)
COIL INSIDE DIAMETER (ENTRY) – 20” (508 mm) TO 32” (813 mm)
COIL INSIDE DIAMETER (EXIT) – 20” (508 mm) OR 24” (610 mm)
SLITTER ARBOR DIAMETER – 9” (228 mm)
NUMBER OF SLITTER HEADS – TWO (2) 72” (1,829 mm) HEADS
SLITTER HEAD EXCHANGE STYLE – POWERED INJECTOR WITH CAROUSEL
LINE SPEED – 450 – 950 FPM (137 MPM – 274 MPM)
UNCOILER DRIVE – ELECTRIC FEED-UP w/ WATER-COOLED BRAKE
SLITTER DRIVE – 150 HP
SCRAP CHOPPER – BUTECH 251 CHOPPERS
RECOILER DRIVE – 300 HP
SLITTING LINE COMPONENTS:
FOUR (4) ARM ENTRY STORAGE TURNSTILE
FLOOR LEVEL COIL LOADING CAR
CANTILEVERED MANDREL UNCOILER w/ HOLD DOWN ROLL & WATER-COOLED BRAKE
UNCOILER OUTBOARD SUPPORT
UNCOILER FILLER PLATES FOR LARGER COIL ID
