Equipped With
Manufacturer: Corimpex
Web Height: 200mm - 1500mm
Web Thickness: 5mm - 30mm
Flange Width: 150mm - 700mm
Flange Thickness: 6mm - 50mm
Thickness Post-Deformable: up to 28mm
Max. Beam Weight: 800 kg/m
Max. Cylinder Stroke: 1300mm
Max. Cylinder Force: 9 Tons
Travel Speed of the Beam on the Conveyors: 12 m/min
Welding Speed: 0.15 - 2.1 m/min
Type of Beams Welded: H, I, T, L, Star Beams, Box
Longitudinal Tipology: Straight, Conical & Cambered
Welding Technology: Sub Arc - Single Wire, Twin Arc, Tandem
