2500mm x 16mm x 35 Ton FIMI Cut-to-Length Line with Flying Shear
2500mm x 16mm x 35 Ton FIMI Cut-to-Length Line with Flying Shear
2500mm x 16mm x 35 Ton FIMI Cut-to-Length Line with Flying Shear
  • 2500mm x 16mm x 35 Ton FIMI Cut-to-Length Line with Flying Shear
  • 2500mm x 16mm x 35 Ton FIMI Cut-to-Length Line with Flying Shear
  • 2500mm x 16mm x 35 Ton FIMI Cut-to-Length Line with Flying Shear

2500mm x 16mm x 35 Ton FIMI Cut-to-Length Line with Flying Shear

Brand
FIMI

Model
Not Specified

Type
Cut To Length Lines

Stock #
604970

Condition
Used

Year
1984

Request a Quote
Have one to sell?
Coil Weight 70000 pounds
Width 98.5 inches
Thickness .63 inches
ID 34 inches
Max OD 86.5 inches

Equipped With

Manufacturer: FIMI
Material: Hot Rolled Steel
Strip Width : 750mm to 2500mm
Strip Thickness Range: 6-16 (18mm)
Coil OD: 1000mm to 2200mm
Coil ID Range: 508 to 860mm
Max Coil Weight: 35 Ton
Package Width: 750mm to 2550mm
Package Lenght: 750mm to 12,000mm
Working Speed: 16 m/min
Pass Line Height: 1500mm
Line Direction: Left to Right

Complete Line with the Following Components:

Pit Type Coil Car

Double Cone Uncoiler

Free Standing Peeler/ Hold Down Roll

9 Roll Straightener
Work Roll Diameter: 180mm

Flying Shear

Run Out Table

Stacker

Complete with Hydraulics, Electrics, Controls.
