1650mm (65") x 2mm Stamco Tension Leveling Line (1992)

1650mm (65") x 2mm Stamco Tension Leveling Line (1992)

Brand
STAMCO

Model
Not Specified

Type
Tensioning Lines

Stock #
605247B

Condition
Used

Year

Request a Quote

Have one to sell?

Specifications
Files & Attachments

Width	65 inches
Thickness	.06 inches
Coil Weight	24000 pounds

Equipped With

• 27.6” (700mm) x 65” (1650mm)

• Manufacturer: STAMCO USA 1992

• Revamped by SIMGE 2022 ready for install

Technical Specifications:

• Width: 700mm – 1650mm

• Max/Min Thickness: 0.2mm – 1.5mm

• Max. Tensile Strength: 350 MPa

• Line Speed: 180 mpm max

• Max Coil Weight: 12,000 Kg

• Uncoiler Data:

• Spool ID: 320/382/400/500 (600mm)

• Coil OD: 2200mm

Recoiler Data

• Spool ID: 320/382/400/500 (600mm)

• Coil OD: 2200mm

• Working direction: Right to left

• Strip Edge Control

• Bending Leveler Section

• Work Roll 35mm - 38mm

• Backup Roll: 135mm

• 3 Strip Tension Stations

• Edge Trimming Shear & Scrap Winder

• Strip Press

• New Control Panel & Software

• Complete Controls, Electric & Hydraulics

• Belt Wrapper

Uninstalled
