| Tonnage | 14000 tons |
| Stroke | 2600 millimeters |
| Daylight | 5700 millimeters |
| Power | 220 kilowatts |
| Bed Width | 3000 millimeters |
| Bed Length | 13000 millimeters |
| IPM | 3.3 meters-per-minute |
Capacity:
700mm Diameter @ 45mm
2000mm Diameter @ 130mm
Stroke: 2600mm
Daylight: 5700mm
Slide area: 12500mm x 1800mm
Table area: 15500mm x 2000mm
Work size: 13000mm x 3000mm
Normal pressure: 280kg/cm2
Maximum work pressure: 315 kg/cm2
Main motor: 220KW, 6P, 6000V, 50Hz, 2 units
