• 9” (228mm) x 22” (559mm) x 40” (1016mm)
• Manufacturer: Hunter
Technical Specifications:
• Width: 457mm – 1016mm
• Entry Thickness: 0.38mm
• Exit Max/Min Thickness: 0.3mm/ 2mm x 0.007mm
• Line Speed: 730 mpm max
• Max Coil Weight: 2000 kg.
Mill Data:
• Work Roll Face: 1016mm
• Work Rolls Diameter: 228 mm
• Back-Up Rolls Diameter: 559mm
• 223.7 kW Motor Drive
• Uncoiler Data:
• Coil ID: 270mm/400mm
• Coil OD: 914mm
• Uncoiler 1: 1 x 18.6 kW Motor Drive
• Uncoiler 2: 1 x 18.6 kW Motor Drive
Recoiler Data:
• Coil ID: 270mm
• Coil OD: 914mm
• 2 x 14.9 kW Motor Drive
• Control System H by Fata / Siemens (needs to be updated)
• NDC X Ray Thickness measurement (needs to be updated)
• Complete Hydraulics, Controls & Electric (needs to be updated)
• Morgoil Lubrication System
• Entry & Exit Coil Rack
• Edge Trimmer
Available Rolls & Spare Parts
• Steel Cores
• Coolant System
Installed
